Intermatic Mechanical Timer PB913N84

Intermatic Mechanical Timer PB913N84

Intermatic Timer PB913N84 provides automatic control for hot tubs, spas, pumps, cleaners and other types of loads. Timers have three-way mounting; flush in round opening, raised in rectangular opening or on base. Quick connect terminals for easy installation.

Applications:

• Spas, Filter Pumps, Booster Pumps, Sprinkler Systems, Heating Systems, Hot Tubs, Lights, Fountains, Cleaning Systems, Security Systems, etc.

Timer Cycle:

• Timing Cycle - 24 hour timer dial
• 4 Trippers - 30 minute per peg
• Minimum On time - 1 hour
• Maximum On time - 23 hours
• Manual Override

Dimensions:

• Height: 3-3/16"
• Width: 2-3/4"
• Case only depth: 1-5/8"

Electrical Rating:

• 20 Amps resistive - 120-277 volts
• Motor Voltage: 120 Volts

Intermatic PB913N84
